描述
| CPU Support | Intel |
| CPU Socket | FCLGA 3647 Square ILM |
| Screw Type | M4 |
| Installation Torque | 12 in-lb |
| Solution | 3U Server and Up |
| Dimensions | 179.2 x 87.5 x 85.6 mm |
| Weight | 550 g |
| Material | Aluminum Heatsink with Heatpipe Embedded & Copper Base |
| Fan Dimension | 60 x 60 x 28 mm |
| Speed | At Duty Cycle 20%: 1600 ± 200 RPM At Duty Cycle 50%: 4000 ± 10% RPM At Duty Cycle 100%: 8000 ± 10% RPM |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12V |
| Power | At Duty Cycle 20%: 0.90 W At Duty Cycle 50%: 2.16 W At Duty Cycle 100%: 14.4 W |
| Air Flow | At Duty Cycle 20%: 9.26 CFM At Duty Cycle 50%: 23.16 CFM At Duty Cycle 100%: 46.32 CFM |
| Noise Level | At Duty Cycle 20%: 19.15 dBA At Duty Cycle 50%: 39.05 dBA At Duty Cycle 100%: 54.10 dBA |
| Air Pressures | At Duty Cycle 20%: 0.75 mm-H2O At Duty Cycle 50%: 4.67 mm-H2O At Duty Cycle 100%: 18.68 mm-H2O |
| Lead Wire Pin Out | Lead Wire Pin Out Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
| Life – Continuousoperating undernormal temperature(40 °C or 107 °F) | 70,000 Hours |
| Thermal Grease | Shin-Etsu 7762 Pre-printed |
*所有产品规格和产品图片均可能在不经通知的情况下更改。
