描述

CPU Support
Intel
CPU Socket
LGA 115X/1200
Screw Type
M3
Installation Torque
5-7 in-lb
Dimensions
93.0 x 31.0mm
Solution
1.5 U, Mini-ITX (with chassis height 2 inch & up)
Weight
185 g
Fan Dimension
80 x 80 x 15 mm
Material
Aluminum 6063-T5 Extruded Radial Fin
Rated Voltage
12V
Speed
At Duty Cycle 20%: 800 RPM
At Duty Cycle 50%: 1500 RPM
At Duty Cycle 100%: 2500 RPM
Bearing
2 Ball Bearing
Power
At Duty Cycle 20%: 0.36 W
At Duty Cycle 50%: 0.6 W
At Duty Cycle 100%: 2.4 W
Air Flow
At Duty Cycle 20%: 9.24 CFM
At Duty Cycle 50%: 18.48 CFM
At Duty Cycle 100%: 30.80 CFM
Noise Level
At Duty Cycle 20%: 16.0 dBA
At Duty Cycle 50%: 22.0 dBA
At Duty Cycle 100%: 27.3 dBA
Air Pressure
At Duty Cycle 20%: 0.42 mm-H2O
At Duty Cycle 50%: 1.93 mm-H2O
At Duty Cycle 100%: 2.6 mm-H2O
Lead Wire Pin Out
Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)
Life – Continuous operating
under normal temperature
(40 °C or 104 °F)
70,000 Hours

*所有产品规格和产品图片均可能在不经通知的情况下更改。
