CPU Support

AMD

CPU Socket

SP5

Screw Type

M3.5

Installation Torque

12.5-15.1 in-lb

Connector Type

Staubli scg03 male

Hose length

300 mm

Material

Copper cold plate with plastic cover, EPDM hose

Form factor

1U and up

Mounting

Mounting accessories included

Thermal Grease

Shin-Etsu X23-8079-2 Pre-Printed

Max Normal Operating Pressure

25 psi

Max Allowable Pressure

80 psi

Recommended Flow Rate

<2 L/min

Life – Continuous operating

under normal temperature

(40 °C or 104 °F)

70,000 Hours
