描述
*注意：要查找与您的处理器对应的包裹承运商，请访问官方英特尔链接获取更多信息。
Dynatron S2、S3、S4、S5、S6 和 S7 每个都配备 E1B 型号的包裹承运器。
E1A 和 E1C 型号的包裹承运器不包括在内，但可根据要求提供。
|
CPU Support |
Intel |
|
CPU Socket |
FCLGA 4677 |
|
Screw Type |
#8-32 |
|
Installation Torque |
8 in-lb |
|
Solution |
1U Server and Up |
|
Dimensions |
118.0 x 80 x 27 mm |
|
Weight |
424.6 g |
|
Material |
Copper 1100 Heatsink with Vapor Chamber Base |
|
Fan Dimension |
80 x 13 mm |
|
Speed |
At Duty Cycle 0~20%: 2000 ± 200 RPM At Duty Cycle 50%: 4900 ± 10% RPM At Duty Cycle 100%: 8600 ± 10% RPM |
|
Rated Voltage |
12V |
|
Bearing |
Double Ball |
|
Power |
At Duty Cycle 20%: 1.08 W At Duty Cycle 50%: 4.7 W At Duty Cycle 100%: 23.45 W |
|
Air Flow |
At Duty Cycle 20%: 5.59 CFM At Duty Cycle 50%: 14.76 CFM At Duty Cycle 100%: 26.25 CFM |
|
Noise Level |
At Duty Cycle 20%: 23.3 dBA At Duty Cycle 50%: 43.5 dBA At Duty Cycle 100%: 62.2 dBA |
|
Air Pressure |
At Duty Cycle 20%: 3.69 mm-H2O At Duty Cycle 50%: 25.28 mm-H2O At Duty Cycle 100%: 89.80 mm-H2O |
|
Lead Wire Pin Out |
Pin#1-Black(-) |
|
Thermal Grease |
Shin-Etsu 7762 or Equivalent |
|
Life – Continuous operating under normal temperature (40 °C or 104 °F) |
70,000 Hours |
*所有产品规格和产品图片均可能在不经通知的情况下更改。
