描述

CPU Support
Intel
CPU Socket
LGA 2011 (Square Type, 80mm x 80mm Mounting Pitch)
Screw Type
M4
Installation Torque
10-16 in-lb
Solution
2U Server and Up
Dimensions
90.0 x 90.0 x 62.0 mm
Weight
490 g
Material
Aluminum Extruded Radial Fin Heatsink with Copper Inserted
Fan Dimension
77 x 77 x 20 mm
Bearing
2 Ball Bearing
Fan Speed
At Duty Cycle 20%: 1000 RPM
At Duty Cycle 50%: 2500 RPM
At Duty Cycle 100%: 4500 RPM
Rated Voltage
12V
Power
At Duty Cycle 20%: 0.84 W
At Duty Cycle 50%: 1.44 W
At Duty Cycle 100%: 6.0 W
Air Flow
At Duty Cycle 20%: 10.12 CFM
At Duty Cycle 50%: 25.30 CFM
At Duty Cycle 100%: 45.56 CFM
Noise Level
At Duty Cycle 20%: 13.14 dBA
At Duty Cycle 50%: 33.04 dBA
At Duty Cycle 100%: 45.9 dBA
Air Pressure
At Duty Cycle 20%: 0.185 mm-H2O
At Duty Cycle 50%: 1.156 mm-H2O
At Duty Cycle 100%: 3.746 mm-H2O
Lead Wire Pin Out
Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)
Life- Continuous operating
under normal temperature
(40°C/104 °F)
70,000 Hours
*所有产品规格和产品图片均可能在不经通知的情况下更改。
