Intel

LGA1356/1366

2U Server & Up

94.0 x 89.5 x 64.0mm

460g ± 5g

Copper Base & Aluminum Fins with Heat pipes embedded

77 x 77 x 20mm

At Duty Cycle 0%: 1000+ 10%RPM
At Duty Cycle 20%: 1000+ 10%RPM
At Duty Cycle 100%: 5500+ 10%RPM

2 Ball Bearing

12V

At Duty Cycle 0%: 0.54W
At Duty Cycle 20%: 0.54W
At Duty Cycle 100%: 9W

At Duty Cycle 0%: 8.36 CFM
At Duty Cycle 20%: 8.36 CFM
At Duty Cycle 100%: 53.90 CFM

At Duty Cycle 0%: 20.6 dBA
At Duty Cycle 20%: 20.6 dBA
At Duty Cycle 100%: 51.4dBA

Pin1- Black(-)
Pin2- Yellow(+)
Pin3- Green(Techometer/Signal output)
Pin4- Blue(PWM)
