描述

CPU Support
Intel
CPU Socket
FCLGA 3647
Screw Type
M4
Installation Torque
12 in-lb
Solution
2U Server and Up
Dimensions
90.0 x 90.0 x 66.0 mm
Weight
430 g
Material
Aluminum Heatsink with Heatpipe Embedded
Fan Dimension
60 x 60 x 25 mm
Speed
At Duty Cycle 20%: 1400 ± 200 RPM
At Duty Cycle 50%: 3400 ± 10% RPM
At Duty Cycle 100%: 7000 ± 10% RPM
Rated Voltage
12V
Bearing
2 Ball Bearing
Power
At Duty Cycle 20%: 0.90 W
At Duty Cycle 50%: 2.04 W
At Duty Cycle 100%: 5.40 W
Air Flow
At Duty Cycle 20%: 8.12 CFM
At Duty Cycle 50%: 20.31 CFM
At Duty Cycle 100%: 40.60 CFM
Noise Level
At Duty Cycle 20%: 16 dBA
At Duty Cycle 50%: 35 dBA
At Duty Cycle 100%: 50 dBA
Air Pressure
At Duty Cycle 20%: 0.58mm-H2O
At Duty Cycle 50%: 3.65 mm-H2O
At Duty Cycle 100%: 14.58 mm-H2O
Lead Wire Pin Out
Lead Wire Pin Out
Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)
Thermal Grease
Shin-Etsu 7762 or Equivalent
Life – Continuous operating
under normal temperature
(40 °C or 104 °F)
70,000 Hours
*所有产品规格和产品图片均可能在不经通知的情况下更改。
